Rp 32.723.000
DETAIL PRODUCT – MIG-MAG 200S G-SP |
|
| Input Voltage | 1 Phase 220 V ± 15% |
| Frequency | 50 / 60 Hz |
| Rated Input Current | DC SMAW (MMA): 42 A GMAW (MIG-MAG): 35 A |
| Rated Input Power | 7 kVA |
| No-Load Voltage | DC 66 V |
| Range of Output Current | 30 – 200 A |
| Range of Output Voltage | DC SMAW (MMA): 20.4 – 28 V GMAW (MIG-MAG): 15.5 – 24 V |
| Diameter of Welding Wire | Ø 0.6 – 1.0 mm |
| Wire Feed Speed | 3 – 15 m/min |
| Power Source Characteristics | CC-CV (Constant Current & Constant Voltage) |
| Welding Processes | GMAW (MIG-MAG) SMAW (MMA) GTAW (LIFT TIG) FCAW (Gas & Gasless) |
| Type of Machine Feeder | Compact (Built-in) |
| Rated Duty Cycle | 60% |
| Power Factor | ≥ 0.93 |
| Efficiency | ≥ 85% |
| Insulation Class | Class F |
| Protection Class | IP21 |
| Weight | 22.5 kg |
| Dimension (L × W × H) | 477 × 233 × 455 mm |
STANDARD ACCESSORIES
MIG Torch 3M
Electrode Holder Set
Earth Clamp Set
Gas Hose
Hose Clip
Solid Wire 5 kg
TAMBAHAN ACCESSORIES
Argon Gas Regulator-921
Argon Gas With Cylinder 6M2
Tig Torch WP-26V 4M
CO2 Gas With Cylinder 6M2
CO2 Gas Regulator-921
Apron
Arm Sleeve (Pair)
Glove 16″ (Pair)
Auto Welding Helmet
Solid Wire GMAW AWS ER70S-6 (0.8Mm)
Electrode SMAW AWS E6013 (3.2Mm)
8″ Sheet Metal Locking Pliers
9″ Welding Locking Pliers
11″ C Lamps Locking Pliers
