STANDARD ACCESSORIES
Euro Connector 2 Pcs
MULTIPRO MMA 400I G-KR-EDU
Rp 15.922.000
MULTIPRO MMA 400I G-KR-EDU
ITEMS NUMBER : 5.315.399.131E
DETAIL PRODUCT |
|
| Input Voltage | 3 Phase 380 V + 15% |
| Frequency | 50 / 60 Hz |
| Rated Input Power | 17 kVA |
| Rated Input Current | 24 A |
| Range Working Voltage | 36 V |
| No-Load Voltage | 81 V |
| Range of Output Current | 40 – 400 A |
| Electrode Diameter | Ø 2.6 – 8.0 mm |
| Rated Duty Cycle | 60% |
| Power Factor | ≥ 0.99 |
| Efficiency | ≥ 85% |
| Insulation Class | Class H |
| Protection Class | IP21S |
| Weight | 30 kg |
| Dimension (L × W × H) | 582 × 352 × 590 mm |
SUITABLE FOR
Electrode 2.8 ~ 8.0 mm (Basic & Rutile) (AWS E6013, E7018, E7016, Etc.)
Work with Generator
Medium & Heavy Industrial
